Fully Automatic Precision Surface Grinder – FSG-2460ADIV
| ITEM | Description | S.A.E. | Metric |
|---|---|---|---|
| Control | iSurface | – | – |
| Capacity | Grinding length | 59.1″ | 1,500 mm |
| Grinding width | 23.6″ | 600 mm | |
| Distance table to centerline of wheel | 33.5″ | 850 mm | |
| Max. table load | 3,968 lbs. | 1,800 kg | |
| Table | Table size | 23.6″ x 59.1″ | 600 x 1,500 mm |
| Table speed (variable) | 16~82 fpm | 5-25 m/min | |
| Max. table travel | 63″ | 1,600 mm | |
| Transverse movement (Z) | Max. travel | 26.6″ | 675 mm |
| Feed speed | 0~7.38 fpm | 0~2,250 mm/min | |
| Wheelhead movement (Y) | Max. travel | 26.6″ | 675 mm |
| Feed speed | 0~2.2 fpm | 0~675 mm/min | |
| Spindle | Spindle speed | 500~1,800 rpm | – |
| Spindle motor | 15 HP | 11 kW | |
| Wheel dimension | OD x Width x Bore | Ø16″ x 3″ x Ø5″ | Ø405 x 75 x Ø127 mm |
| Machine dimensions | Floor space (W x D x H) | 194.8″ x 144.1″ x 110.2″ | 4,950 x 3,660 x 2,800 mm |
| Net weight | 21,600 lbs. | 9,800 kg |
