YHK31125 CNC Gear Hobbing Machine High Working Accuracy CNC Gear Hobbing Machine
Products Description
The machine adopt SlEMENS CNC system and the AC servo motors, can achievethe two-axis.
The machine is suitable for large and single production of cylindrical spurand helical gears,worm gears,sprocket,drum Gear and Spline shaft.
The machine is characterized by good rigidity ,high working accuracy , easyin operation and maintain.
The machine can be operated not only with forward and backward cutting , butalso with axial or radial feed.
The machine is suitable for large and single production of cylindrical spurand helical gears,worm gears,sprocket,drum Gear and Spline shaft.
The machine is characterized by good rigidity ,high working accuracy , easyin operation and maintain.
The machine can be operated not only with forward and backward cutting , butalso with axial or radial feed.
Product Parameters
|
Model
|
YHK31125
|
|
No. of controlling axes
|
2
|
|
Max. work piece dia. (without work stay)
|
1000/1250 mm
|
|
Max. module(steel/cast iron)
|
16/18 mm
|
|
Max. width of teeth
|
450 mm
|
|
Max. hob diameter / length
|
245/220 mm
|
|
Max. hob shift axial
|
100mm
|
|
Taper of hob arbor fitting
|
MT6
|
|
Center distance between hob and worktable
|
100~750 mm
|
|
Distance between hob axis and worktable surface
|
200~700 mm
|
|
Distance between tailstock and fece and worktable surface
|
500~900 mm
|
|
Dia. of worktable
|
950 mm
|
|
Worktable bore diameter
|
200 mm
|
|
Max hob swiveling angle
|
±60°
|
|
Spindle speed
|
16~125 rpm
|
|
Max. worktable speed
|
3.5 rpm
|
|
Main motor
|
15kw/1500rpm
|
|
Overall dimensions LXWXH
|
3616/2040/2450 mm
|
|
Eight
|
14750/13000kg
|
